10.4" AHD Quad Monitor

Brigade VBV-7104HFM 7" AHD Quad Monitor 4 Camera input

Features

• 12-24Vdc
• Size (WxHxD): 267 x 193 x 30mm
• 3 year warranty
• AHD and CVBS compatible
• High-definition, high contrast, wide view angle
• 3 camera inputs
• 3 Auto-triggers
• Mirror / Normal switching from menu
• ‘Button lock’ anti-tamper feature
• On-screen distance markers
• Audio
• Sun shield
• Auto-dimmer
• Multi-lingual menus
• Auto-switching AHD 1.0 / AHD 2.0 / PAL / NTSC

Picture Quality

• LED backlighting (gives 20,000 hours life)
• Anti-glare screen
• Resolution: 1024 x 600
• Contrast ratio: 700:1
• Brightness: 500cd/m2
• Viewing angles: Side 85° x Top 85° x Bottom 85°

Power

• Power consumption: 10 Watts
• Current: 0.8 Amps

Durability & Standards

• Mechanical vibration: 4G
• Mechanical shock: 51G
• Operating temperature: -30 to +70°C
• CE marked
• E-Marked: UNECE R10 compliant
• HALT tested
• FCC approved
• IC approved
